xTool 40W Laser Module for D1 Pro

Ships to CA in 1-3 business days.
CAD $999.00 CAD $1,999.99

CAD $999.00 CAD $1,999.99
Ships to CA in 1-3 business days.

Join Live: Women's Day Gift! Laser Engrave with xTool.

1. Lucky Draw: Win FREE Enclosure + Vinyl Packs
2. Live Sale: Up to 30% OFF!
3. Tutorial: Women's Day Gift Making with xTool!

Sign Up for More Suggestion and Deals

xTool D1 Pro

40W Diode Laser Module

xTool D1 Pro

40W Diode Laser Module

The World's First
40W Diode Laser Module

The World's First

40W Diode

Laser Module

The latest 8*5.5W laser compression technology.

The latest 8*5.5W laser

compression technology

The Mightiest Cutting Ability

The Mightiest
Cutting Ability

18mm hardwood cutting in one-pass

15mm black acrylic cutting in one-pass

0.1mm stainless metal cutting in one-pass

Maximum thickness of one-pass cutting

Laser Module40W20W
Pine Wood20mm15mm
Cherry Wood18mm10mm
Basswood Plywood15mm10mm
Walnut Wood15mm10mm
Black Acrylic15mm8mm
Stainless Metal0.1mm0.04mm

The Highest Working Efficiency

The Highest Working Efficiency

Bringing Brighter Colors to the Engraved Metal

40W stainless metal engraving

20W stainless metal engraving

You Can Easily Hammer More Creative Products

You Can Easily Hammer More Creative Products

Excellent Heat Dissipation System Ensures the Best Optimal Performance

Excellent Heat Dissipation System Ensures the Best Optimal Performance

With the excellent Heat Dissipation system containing a laser fan and the meticulously designed internal structure, the heat generated by the 40W ultra-high laser module can be quickly dissipated and the temperature is controlled to ensure the best optimal processing performance.

With the excellent Heat Dissipation system containing a laser fan and the meticulously designed internal structure, the heat generated by the 40W ultra-high laser module can be quickly dissipated and the temperature is controlled to ensure the best optimal processing performance.

Fast-assembled with
Brand New Design

Fast-assembled with Brand New Design

Built-in Air Tube

Plug in the air tube and connect air assist accessories; no need for external adapter parts.

Built-in Air Tube

Plug in the air tube and connect air assist accessories. No need for external adapter parts.

Retaining Clip

It is more convenient and quicker to change the laser module.

Magnetic Light Shield

Clean and easy to use with plug-and-play magnetic light shield.

Magnetic Light Shield

Clean and easy to use with plug-and-play magnetic light shield.

What's inside the box?

Notice for xTool D1 Pro 2.0 Users

D1 pro 2.0 only requires the following parts. The remaining parts are for adaptation to D1 pro 1.0.

PC.jpg__PID:3d0a280d-4c90-439c-b9f8-4797cf5cf1bbAPP.jpg__PID:4f3d0a28-0d4c-4083-9c39-f84797cf5cf1

Specification

TypexTool D1 Pro-40W Laser Module
Machine Power200 W
Laser Electric Power144 W
Laser Module Output Power40W
Laser Spot0.1*0.15mm
Routing Speed400 mm/s
Working Area 430*348mm (16.93 * 13.7 inches)

Expandable to 909*430mm (35.79*16.93 inches) with xTool Extension Kit
Max. Workpiece Height50 mm (2 inch)
Max. Workpiece Height with X risers  50mm+X*45mm(each set riser height column)
Connecting InterfacesUSB/Wi-Fi/TF Card
CertificationFCC / FDA / CE
Operating SystemsWindows/macOS
Control SoftwarexTool Creative Space / LightBurn
File Type(s)SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc.

FAQ

United States (most states)*, Canada, Australia, New Zealand, South Africa, Israel, Singapore, and China (mainland and Hongkong SAR). For more information, please check here

 *Not yet available states in the Canada:Northwest Territories, Nunavut

Customer Reviews

Based on 2 reviews
50%
(1)
0%
(0)
50%
(1)
0%
(0)
0%
(0)
J
JBK
Happy With The 40W Module Upgrade

I bought the 40W upgrade module during a sale at about 50% off. The unit was shipped very quickly and arrived a few days before the estimated date. Packaging was top notch and the instructions were intuitive. The whole process took less than an hour. To test it, I ran a job that had my 10W module struggling. It completed the job in about 1/3 the time and without the pauses that the 10W encountered. I am very happy with this upgrade.

D
David Bailey
Not as amazing as I was expecting

Don't get me wrong. It works fine. Upgrading my old D1 pro to this module was easy enough. The instructions were not too bad if a little small. I also added the extended bed, and there are no instructions with that and that experience was awful. But that is not part of this review. The 40W head definitely cuts thicker material than the 20W head, but not double, as expected. So of course it is faster, etc. but given the very high cost of the value proposition proposition just seems middle of the road for me.
The other important thing to remember is that when you are cutting thicker material, you have a massive burned edge to deal with on whatever it is you are cutting out. And that massive burned edge of plywood or hardwood or softwood needs to be dealt with in some manner. You will have black char all over the place. It is messy. I have a full woodworking shop and many tools at my disposal, including a router, jointer and multiple Sanders and I tried them all. I settled on cleaning up straight edges with the jointer. If you do not have access to tools, like this and are relying on hand sanding, or just sealing the edge, or some other method than beware that you are in for some work.
So is it the right tool for cutting out project parts out of 16 mm wood? Maybe or maybe not. It is certainly faster than a bandsaw, but I wonder if a CNC machine would have worked better for my projects.
I am able to cut birch plywood up to 16 mm in two passes and 16 mm cedar in one pass that ends up looking like a forest fire or in two passes for a better look.
