Super Versatile and Functional
You can easily change the structure to process different objects but get the same amazing results.
Roller Rotary
Extra length
Extra diameter
Irregular cylinders
Chuck Rotary
Vector engraving
Mugs
Tumblers
Sphere Rotary
Balls
Vector engraving
25mm-100mm
Ring Rotary
Rings
Vector engraving
11mm-70mm
Meet all Your Needs
From home to outdoor, from party to sport, RA2 Pro suitable for 90% daily use cylinders and spheres. Make unique wedding wine glasses and custom jewelry.
Higher Speed and Accuracy
360°/s
maximum angular speed
0.45°
precise control
0-100mm
diameter range
*360°/s speed is for 37mm diameter cylinder.
*The diameter range here is in the case of engraving with Chuck Rotary.
Efficient Vector Engraving
Won't Slip All the Time
Compatible with Other Brands
Compatible with xTool D1 and other laser engraving machines with open structure.
LightBurn
The layout, editing, and control software for common laser cutter. Engraving file format supports NC, BMP, JPG, PNG, DXF, etc.
LightBurn Support
The layout, editing, and control software for common laser cutter. Engraving file format supports NC, BMP, JPG, PNG, DXF, etc.
Learn more about software > > >
LaserGRBL
Free laser engraving software that is able to load any image, picture and logo and send to your laser engrave with few clicks.
Small Details. Big Differences.
Soft-pad Jaws
Soft-pad covered on jaws provide a larger friction force, and prevent brittle objects from breaking.
More Choice for Jaws
xTool RA2 Pro comes with double step jaws and single step jaws. Users can also 3D print their own jaws to work with more objects.
More Choice for Jaws
xTool RA2 Pro comes with double step jaws and single step jaws. Users can also 3D print their own jaws to work with more objects.
Separable Level Tool
Keep the center of objects stable all the time, especially for irregular and extra-long cylinders.
Easy to use
Smart mechanical structure design makes it easier to adjust the support module height and the chuck diameter.
Easy to use
Smart mechanical structure design makes it easier to adjust the support module height and the chuck diameter.
Specification
| Product Name | RA2 Pro |
|---|---|
| Product Size | 321*138*105mm |
| Package Size | 460*182*95mm |
| Package Weight | 2.33kg |
| Compatible with | xTool D1, D1 Pro and other open laser engravers |
| Gear ratio | Chuck 4:1 |
| Chuck diameter | 50mm |
| Engrave diameter range (Use additional risers) | Roller: 3mm-198mm Chuck: 0mm-100mm Sphere: 25mm-100mm Ring: 11mm-70mm |
| Software | xTool Creative Space LightBurn LightGRBL |
